FOX PODIUM UTV POWERSPORTS DUAL SEAL SCHRADER HIGH VOLUME 2.5 RESI END CAP (2.250 BORE) UPGRADE KITS

Regular price $99.95

Shipping calculated at checkout.

GIVE YOURSELF THE ABILITY TO CHECK NITROGEN PRESSURE QUICK AND EASY VS THE OEM FOX NEEDLE VALVE.

FOX PODIUM POWERSPORTS RESERVOIR END CAP KITS WITH DUAL O-RING SEAL, FACE SEAL BILLET SCHRADER CAP AND O-RING BOSS SEALED SCHRADER VALVE FOR EASY ROUTINE MAINTENANCE WITH CHECKING AND CHARGING NITROGEN.

FOR STEPPED RESERVOIRS ONLY

FEATURES:
-DUAL O-RING DESIGN. 1 VITON AND 1 BUNA ORING FOR 2X SEALING OVER OEM.
-OEM STYLE 7/16-20 O-RING BRASS CHARGE VALVE IMPROVES SEAL OVER CHARGE PELLET OR PIPE THREAD VALVE
-INCREASED VOLUME DECREASES GAS RAMP WITH HIGH TEMPS/EXTREME USAGE
-HD BILLET SCHRADER CAP WITH O-RING FACE SEAL FOR REDUNDANT NITROGEN SEAL.
-HD BILLET CAP ADDS STRENGTH / DESCREASES RISK OF BREAKING SHCRADER VALVE OFF VS STANDARD CAP
-6061 ALUMINUM CAP AND RESI END CAP
-HARD ANODIZE FINISH ON BOTH END CAP AND SCHRADER CAP FOR IMPROVED DURABILITY OVER THE OEM DECORATIVE ANO FINISH.
-LASER ETCHED SHOCKSEALS.COM LOGO 2 PLACES.

SOLD AS 1 COMPLETE PAIR OF END CAP ASSMEBLIES (2 RESERVOIRS WORTH)
NOT SOLD INDIVIDUALLY.

DEALER INQUIRIES ALWAYS WELCOME

FITMENT:
FOX 2.5 ALUMINUM POWERSPORT RESERVOIRS WITH 2.250 BORE THAT UTILIZE THE NEEDLE CHARGE END CAP(226-00-267-X) AS SHOWN IN PICTURES. RESERVOIR MUST HAVE THE STEP IN END THAT KEEPS RESI END CAP FROM PUSHING INTO THE 2.250 DIA BORE OF RESI DURING ASSEMBLY.

HONDA TALON LIVE VALVE AND NON LIVE, POLARIS RZR 800/900/1000 XP WITH AND WITHOUT TURBO, TURBO S, XP PRO, PRO R, TURBO R, CAN AM, YAMAHA YXZ. IF YOU HAVE A FOX SHOCK ON A UTV OR POWERSPORT WITH A CAP THAT LOOKS LIKE THE COMPARISION PICTURE SHOWN WITH A STEP, THESE WILL FIT AND BE A NICE UPGRADE.

INSTALL TIME: 3-5 MINUTES PER CORNER WITH SHOCKS STILL MOUNTED ON VEHICLE.

SHOCKSEALS.COM PN: AHD-F25-CAP-PAIR, AHD-F25-CAP-2PAIR

FOX PN INDIVIDUAL: 802-00-013-KIT SCHRADER VALVE, 010-00-223 BILLET SCHRADER CAP, 226-00-267-X OEM NEEDLE END CAP
FOX PN RETRO: 803-00-977
